Description of Powder bag-making filling cutting counting weight sachet packing machine
Combined weighing packaging machine, as the name suggests, uses a weighing method to ensure the quality of the packaged product, and integrates the elements of automatic packaging to make the product packaging process smoother. The puffed food packaging machine has a series of automatic functions such as automatic feeding, metering, bag making, filling, sealing, date printing and finished product output.
Main performance and characteristics of 3 / 4 side powder pouch packing machine:
1. All tasks such as filling, metering, bag making, sealing, cutting, hot pressing, batch number, etc. can be automatically completed during the packaging process, and there is no need to adjust the photoelectric tracking and positioning.
2. Intelligent control system, LCD display screen in Chinese and English. The operation of the system can be precisely controlled by only setting the parameters.
3. The heat sealer controls the uniform heating of the bag edges, and the upper and lower sides can be individually adjusted for temperature.
4. Changing the cutter can realize in-line, pattern-shaped cutting, and in-line joint cutting, bag cutting is stable and reliable, no bag jamming, simple operation, can be equipped with a wheel-type coding machine to arrange batch numbers, shelf life, etc.
5, Automatic finish weight, bag-making, filling, sealing, cutting, counting, lot number and so on；
6, Automatic optimization match with all the program, this system can alternate the length of bag , thus it is easy and precise；
7, It has color system controller, so can get the complete trade mark design；
8, The length of bag and bag packing speed can be alternated by chain-gear stepless speed various without change spare part；
9, Unique in-laidembedded mouth sealing, enhanced hot sealing mechanism;
Scope of application:
It is suitable for food, medicine, chemical, daily chemical, fertilizer and other production and processing industries.
Puffed food, potato chips, candy, pistachios, raisins, glutinous rice balls, meatballs, peanuts, biscuits, jelly, candied fruit, walnuts, pickles, frozen dumplings, almonds, salt, washing powder, solid beverages, oatmeal, pesticide particles, etc. Flake, short strip, powder and other items.
The features of full-automatic of 3 / 4 side powder pouch packing machine:
1, Speed Limitless: Packing speed shall be limitless arranged in some extend , which can best match the steps of making bag/fulfilling/sealing and cutting .
2, The bag length can be set free at some specific range , using the “Bujin” Motor , making bags stable and the speed can be controlled .
3, The process of bag-made can reach self-automatic inspecting/location/sealing and cutting when there are the signs of color locating in packing films .
4, Equipment itself has the function of self-diagnosing and error-pointing .
5, Controlling temperature by high exact PID , which ensure the sealing quality of different packing film material and will be in more stable of hot sealing .
Equipment list of 3 / 4 side powder pouch packing machine:
| Items | Description | Model | Size-mm |
| 1.1 | Full-Automatic Back Seal Coffee Powder Packing Machine | 3 / 4 side sealing | 850*800*1750 |
| OPTIONS: |
| 1.2 | Ribbon Code Printer | Remark: options based on requirements |
| 1.3 | Protecting cover |
| 1.4 | Conveyor |
Parameters of 3 / 4 side powder pouch packing machine
| Model | 280K |
| Capacity | 30-50bags/min |
| Range of measurement | 25-50g/Bag( 7g can deploy the layer cup) |
| Bag Size | (L)40-150mm (W)40-100mm |
| Sealing type | Three / four sides sealing |
| Accuracy | 2% |
| Power | 1.2KW |
| Voltage | 220V/50-60HZ |
| Packing material | Paper/the polyethylene,polyester/aluminum foil/polyethylene,nylon/polyethylene,tea filter paper,etc |
| Net weigh | 200kgs |
| Gross weigh | 260kgs |
| Overall Dimension | (L)750*(W)700*(H)1600mm |
| After packing | (L)850*(W)800*(H)1750mm |
Product Tags:
|
|
Powder Bag Making Filling Cutting Counting Weight Sachet Packing Machine Images
|
